HIK DS-PDBG8-EG2-WE Wireless Glass Break Detector
HomeStore

HIK DS-PDBG8-EG2-WE Wireless Glass Break Detector

HIK DS-PDBG8-EG2-WE Wireless Glass Break Detector

$350,000.00

Original: $1,000,000.00

-65%
HIK DS-PDBG8-EG2-WE Wireless Glass Break Detector—

$1,000,000.00

$350,000.00

The Story

Wireless Glass Break Detector

  • High quality Omni-directional microphone sensor
  • Fully remote configurable through App
  • Multiple enrollment method and easy installation design
  • Easy replaceable battery with PCB protected
  • Frequency hopping against jamming for reliable transmission

Available models:

DS-PDBG8-EG2-WE

Product Data

  • Detection Performance
  • Detection MethodAcoustic Sensor
  • Detection Range8m
  • Detection Angle120°
  • Sensitivity2m;4m;6m;8m
  • Glass TypeFloat;Plate;Tampered;Wired;Laminated Leaded;Double Glazing
  • Glass Thickness2.4mm to 6.4mm
  • Glass Size0.3m x 0.3m to 3m x 3m
  • Feature
  • Digital ProcessingSupport
  • Tamper ProtectionFront;Rear
  • Environment Temperature IndicatorSupport
  • Signal Strength IndicatorSupport
  • Interface
  • Alarm InputNormally Closed;Normally Open;Impulse Count
  • Power SwitchPower Up Enrolling
  • LED IndicatorBlue(Alarm)
  • Transmission
  • Transmission TechnologyTri-X Wireless
  • Transmission MethodTwo-Way RF Wireless
  • Transmission Frequency868MHz
  • Transmission SecurityAES-128 Encryption
  • Transmission Range(Free Space)1.6Km
  • Frequency HoppingSupport
  • Enrolling MethodPower up;Remote ID;QR Code
  • Electrical Characteristics
  • Power SupplyBattery Powered
  • Battery TypeCR123A × 2
  • Typical Voltage3V
  • Standard Battery Life

    5 years in work status (being triggered 20 times per day)
  • General
  • Operation Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Storage Temperature-20 °C to 60 °C (-4 °F to 140 °F)
  • Operation Humidity10% to 90%
  • Dimension(WxHxD)38.8mm × 107.0mm × 24.5mm
  • 83g
  • Mounting MethodWall;Ceiling
  • Application ScenarioIndoor
,
  • Detection MethodAcoustic Sensor
  • Detection Range8m
  • Detection Angle120°
  • Sensitivity2m;4m;6m;8m
  • Glass TypeFloat;Plate;Tampered;Wired;Laminated Leaded;Double Glazing
  • Glass Thickness2.4mm to 6.4mm
  • Glass Size0.3m x 0.3m to 3m x 3m
,
  • Digital ProcessingSupport
  • Tamper ProtectionFront;Rear
  • Environment Temperature IndicatorSupport
  • Signal Strength IndicatorSupport
,
  • Alarm InputNormally Closed;Normally Open;Impulse Count
  • Power SwitchPower Up Enrolling
  • LED IndicatorBlue(Alarm)
,
  • Transmission TechnologyTri-X Wireless
  • Transmission MethodTwo-Way RF Wireless
  • Transmission Frequency868MHz
  • Transmission SecurityAES-128 Encryption
  • Transmission Range(Free Space)1.6Km
  • Frequency HoppingSupport
  • Enrolling MethodPower up;Remote ID;QR Code
,
  • Power SupplyBattery Powered
  • Battery TypeCR123A × 2
  • Typical Voltage3V
  • Standard Battery Life

    5 years in work status (being triggered 20 times per day)
,
  • Operation Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Storage Temperature-20 °C to 60 °C (-4 °F to 140 °F)
  • Operation Humidity10% to 90%
  • Dimension(WxHxD)38.8mm × 107.0mm × 24.5mm
  • 83g
  • Mounting MethodWall;Ceiling
  • Application ScenarioIndoor
