$1,000,000.00
HIK DS-D4460FO-CKI Outdoor Fixed LED Displays—
$1,000,000.00
The Story
Outdoor Fixed LED Displays
- Widely applied in outdoor permanent advertising scenes
- Thin and light cabinet with the die-casting aluminum design
- IP 65 rating for both front and back
- Free of air conditioners with multiple ventilation modes working together inside the cabinets
- Standing, wall mount, and lifting available for installation
- Customizable as stadium LED screens
Available models:
DS-D4460FO-CKI
Product Data
- Cabinet
- Pixel Configuration1R1G1B
- Pixel Pitch CategoryP6
- Pixel Pitch5.7 mm
- Modules Component3 × 6
- Dimensions (W × H × D)960 mm × 960 mm × 138 mm (37.80'' × 37.80' '× 5.43'' )
- Resolution168 × 168
- Area0.9216 m?
- 50 kg (110.23 lb.)
- Pixel Density30625 dots/m?
- Lamp Board HousingWith housing
- Cabinet MaterialWaterproof sheet metal box
- Maintenance MethodBack maintenance
- Cabinet Flatness0.2 mm
- Protection LevelIP65
- Key Material
- Lamp EncapsulationHG 1921
- Control SystemDS-D42C04-N、DS-D42C06-N
- Display
- White Balance Brightness4500 nits
- Color Temperature3500K to 9300K adjustable
- Viewing AngleHorizontal 140°, vertical 120°
- Contrast Ratio≿5000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 14 bit
- Display Color16777216
- Power
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿1000 W/m?
- Average Consumption< 300 W/m?
- Working Environment
- Working Temperature-20 ℿ to 50 ℿ (-4 ℿto 120 ℿ
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20 ℿto 60 ℿ(-4 ℿto 140 ℿ
- General
- Gross Weight270 kg /5 in 1 (595.25 lb.)
- Package Dimension (W × H × D)1370 mm × 1090 mm × 1180 mm ＿3.93'' × 43.91'' × 46.46''＿/span>
- LifespanLamp 100,000 hours
- Pixel Configuration1R1G1B
- Pixel Pitch CategoryP6
- Pixel Pitch5.7 mm
- Modules Component3 × 6
- Dimensions (W × H × D)960 mm × 960 mm × 138 mm (37.80'' × 37.80' '× 5.43'' )
- Resolution168 × 168
- Area0.9216 m?
- 50 kg (110.23 lb.)
- Pixel Density30625 dots/m?
- Lamp Board HousingWith housing
- Cabinet MaterialWaterproof sheet metal box
- Maintenance MethodBack maintenance
- Cabinet Flatness0.2 mm
- Protection LevelIP65
- Lamp EncapsulationHG 1921
- Control SystemDS-D42C04-N、DS-D42C06-N
- White Balance Brightness4500 nits
- Color Temperature3500K to 9300K adjustable
- Viewing AngleHorizontal 140°, vertical 120°
- Contrast Ratio≿5000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 14 bit
- Display Color16777216
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿1000 W/m?
- Average Consumption< 300 W/m?
- Working Temperature-20 ℿ to 50 ℿ (-4 ℿto 120 ℿ
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20 ℿto 60 ℿ(-4 ℿto 140 ℿ
- Gross Weight270 kg /5 in 1 (595.25 lb.)
- Package Dimension (W × H × D)1370 mm × 1090 mm × 1180 mm ＿3.93'' × 43.91'' × 46.46''＿/span>
- LifespanLamp 100,000 hours
Description
Outdoor Fixed LED Displays
- Widely applied in outdoor permanent advertising scenes
- Thin and light cabinet with the die-casting aluminum design
- IP 65 rating for both front and back
- Free of air conditioners with multiple ventilation modes working together inside the cabinets
- Standing, wall mount, and lifting available for installation
- Customizable as stadium LED screens
Available models:
DS-D4460FO-CKI
Product Data
- Cabinet
- Pixel Configuration1R1G1B
- Pixel Pitch CategoryP6
- Pixel Pitch5.7 mm
- Modules Component3 × 6
- Dimensions (W × H × D)960 mm × 960 mm × 138 mm (37.80'' × 37.80' '× 5.43'' )
- Resolution168 × 168
- Area0.9216 m?
- 50 kg (110.23 lb.)
- Pixel Density30625 dots/m?
- Lamp Board HousingWith housing
- Cabinet MaterialWaterproof sheet metal box
- Maintenance MethodBack maintenance
- Cabinet Flatness0.2 mm
- Protection LevelIP65
- Key Material
- Lamp EncapsulationHG 1921
- Control SystemDS-D42C04-N、DS-D42C06-N
- Display
- White Balance Brightness4500 nits
- Color Temperature3500K to 9300K adjustable
- Viewing AngleHorizontal 140°, vertical 120°
- Contrast Ratio≿5000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿
- Processing Performance
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 14 bit
- Display Color16777216
- Power
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿1000 W/m?
- Average Consumption< 300 W/m?
- Working Environment
- Working Temperature-20 ℿ to 50 ℿ (-4 ℿto 120 ℿ
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20 ℿto 60 ℿ(-4 ℿto 140 ℿ
- General
- Gross Weight270 kg /5 in 1 (595.25 lb.)
- Package Dimension (W × H × D)1370 mm × 1090 mm × 1180 mm ＿3.93'' × 43.91'' × 46.46''＿/span>
- LifespanLamp 100,000 hours
- Pixel Configuration1R1G1B
- Pixel Pitch CategoryP6
- Pixel Pitch5.7 mm
- Modules Component3 × 6
- Dimensions (W × H × D)960 mm × 960 mm × 138 mm (37.80'' × 37.80' '× 5.43'' )
- Resolution168 × 168
- Area0.9216 m?
- 50 kg (110.23 lb.)
- Pixel Density30625 dots/m?
- Lamp Board HousingWith housing
- Cabinet MaterialWaterproof sheet metal box
- Maintenance MethodBack maintenance
- Cabinet Flatness0.2 mm
- Protection LevelIP65
- Lamp EncapsulationHG 1921
- Control SystemDS-D42C04-N、DS-D42C06-N
- White Balance Brightness4500 nits
- Color Temperature3500K to 9300K adjustable
- Viewing AngleHorizontal 140°, vertical 120°
- Contrast Ratio≿5000:1
- Color Uniformity≿± 0.003Cx，Cy
- Brightness Uniformity≿97＿
- Driving MethodConstant current driving
- Frame Frequency60 Hz
- Refresh RateUp to 3840 Hz
- Grey LevelUp to 14 bit
- Display Color16777216
- Power Supply110~220 VAC ± 15%
- Max. Consumption≿1000 W/m?
- Average Consumption< 300 W/m?
- Working Temperature-20 ℿ to 50 ℿ (-4 ℿto 120 ℿ
- Working Humidity10%~80%RH
- Storage Humidity10%~85%RH
- Storage Temperature-20 ℿto 60 ℿ(-4 ℿto 140 ℿ
- Gross Weight270 kg /5 in 1 (595.25 lb.)
- Package Dimension (W × H × D)1370 mm × 1090 mm × 1180 mm ＿3.93'' × 43.91'' × 46.46''＿/span>
- LifespanLamp 100,000 hours
